Corner ProFoams
Clip-on corner foams protecting reveal junctions and vulnerable edges from impact damage.
Corner ProFoams are shaped to fit neatly onto window-frame corners, providing a 100 mm length on each side with a 76 × 51 mm profile (or 80 mm × 50 mm in the standard format). Compatible with all three reveal widths, they are typically paired with 200 mm standard ProFoams to create complete perimeter protection.
Manufactured from closed-cell polyolefin copolymer, these corner units offer a soft, non-marking bearing surface that grips the reveal, compresses under retention, and stays locked in place during transit. Their flexible, long-life material resists water, UV, abrasion, and road debris—ensuring reliable performance in demanding transport environments.
Secure Corner Protection
Clips firmly onto corner reveals to shield vulnerable edges from chips, dents, and abrasion during transport and handling.
Flexible, Long-Life Polymer Construction
Closed-cell polyolefin copolymer flexes without breaking, recovers to its original shape, and offers long service life even under constant compression.
Non-Marking, High-Grip Surface
Soft, textured surface grips the reveal, protects sensitive powder-coated finishes, and prevents movement in transit.
Full Perimeter Compatibility
Designed to clip onto all three reveal widths; used in conjunction with 200 mm standards for complete frame protection.
SPECIFICATIONS
100 mm long per side
Standard profile: 76 × 51 mm or 80 mm tall × 50 mm wide
Closed-cell polyolefin copolymer construction
20 mm thick bearing surface for compression under load
Non-marking, high-grip texture
Fits all three reveal widths
Highly flexible; recovers after compression
UV-resistant and low water absorption
Resistant to abrasive road debris
OPTIONS
Standard Corner ProFoams – 100 mm on each side (80 × 50 mm)
Large Corner ProFoams – 100 mm per side (76 × 51 mm profile)
Custom lengths available for specific applications
DGU edge-protection variants on request
100 mm long per side
Standard profile: 76 × 51 mm or 80 mm tall × 50 mm wide
Closed-cell polyolefin copolymer construction
20 mm thick bearing surface for compression under load
Non-marking, high-grip texture
Fits all three reveal widths
Highly flexible; recovers after compression
UV-resistant and low water absorption
Resistant to abrasive road debris
Standard Corner ProFoams – 100 mm on each side (80 × 50 mm)
Large Corner ProFoams – 100 mm per side (76 × 51 mm profile)
Custom lengths available for specific applications
DGU edge-protection variants on request
